UL1571 Hook-up Wire

UL 1571 Hook-Up Wire — 80°C, 30 Vac, Class 2 Internal Wiring for Electronic Equipment

UL 1571 is a single-conductor appliance wiring material (AWM) with extruded insulation, rated 80°C maximum at 30 Vac with a horizontal flame rating, evaluated under UL Subject 758. Its defining characteristic is the permitted use: internal wiring of Class 2 circuits in electronic equipment, which makes it the go-to style for low-voltage signal and control conductors inside consumer electronics, instrumentation and similar equipment where circuit energy is inherently limited. CableApex supplies UL 1571 as a UL Recognized Component — file on record — from 50 AWG fine-gauge conductors up through heavier sizes in solid or stranded construction.

Eight Insulation Material Options in One Style

Unlike most PVC hook-up wire styles that specify a single insulation compound, UL 1571 covers eight insulation variants within the same style number: extruded PVC, SRPVC (silicone-rubber-modified PVC), foamed PVC, foamed SRPVC, cross-linked PVC (XLPVC), cross-linked SRPVC (XLSRPVC), foamed XLPVC and foamed XLSRPVC. Wall thickness ranges from 2 mils minimum at any point up to 100 mils maximum, giving designers wide latitude to balance flexibility, weight and dielectric strength for a given circuit layout. The cross-linked variants offer improved heat and solvent resistance within the 80°C rating; the foamed variants reduce weight and capacitance in dense wiring harnesses; the SRPVC family adds dimensional stability compared with standard PVC under thermal cycling.

Construction Options: Covering, Shield and Jacket

Beyond the insulation layer, UL 1571 supports an optional covering in PVC, Nylon, ETFE, Polyester, their cross-linked equivalents, or lacquered braid, each at 2 mils minimum thickness. An optional shield and optional jacket (same materials as covering) may be applied over the covering. A second optional shield and second optional covering may then follow, enabling multi-layer constructions that combine electromagnetic shielding and mechanical protection within a single UL-recognised component description. Specify the layers required when requesting a quote so that the correct construction is confirmed against the recognised style.

Fine-Gauge Capability and Where UL 1571 Sits in the Portfolio

The conductor specification begins at 50 AWG minimum — finer than the 32 AWG floor of most general-purpose hook-up wire styles — which makes UL 1571 suitable for the very fine-pitch interconnects found in sensors, hearing instruments and miniaturised electronic assemblies. At 30 Vac, it occupies the lowest voltage tier among CableApex’s PVC-family AWM wire: UL 1007 covers 300 Vac general-purpose hook-up wire, and UL 1032 steps up to 1000 Vac / 1200 Vdc for higher-voltage appliance wiring. Where the downstream circuit is a recognised Class 2 circuit, UL 1571 provides the matching component recognition without the heavier insulation wall of a 300 V or 600 V style.

Permitted Use and How to Order

The permitted use for UL 1571 is internal wiring of Class 2 circuits in electronic equipment. Applications outside this scope require separate confirmation of suitability before specifying. Marking follows UL Subject 758 marking requirements; RoHS/REACH documentation is available on request. CableApex supplies UL 1571 from 100 m per insulation variant and color, with B2B inquiries answered within 12 hours with pricing, lead time and construction details. Browse the UL 1571 products below by AWG size and insulation material, or use any product page form to submit your specification.
