UL 1032 PVC Wire

UL 1032 PVC Wire — 90°C, 1000 Vac / 1200 Vdc Appliance Wiring Material

UL 1032 is a single-conductor appliance wiring material (AWM) with extruded PVC insulation, rated 90°C maximum at 1000 Vac and/or 1200 Vdc with a horizontal flame rating. Evaluated under UL Subject 758, it covers one of the widest conductor ranges of any PVC hook-up wire style — from 30 AWG fine-gauge signal conductors up to 2000 kcmil, in solid or stranded construction — making it a practical single-style solution when an appliance design mixes small control wiring with heavy-section power conductors. CableApex supplies UL 1032 wire as a UL Recognized Component — file on record.

Where UL 1032 Fits Among PVC Hook-Up Wire Styles

The defining feature of UL 1032 is its voltage rating. Standard PVC hook-up wire styles such as UL 1015 stop at 600 Vac, and UL 1007 at 300 Vac. UL 1032 extends PVC insulation to 1000 Vac and 1200 Vdc — the DC rating is particularly relevant for internal DC bus and power-conversion circuits inside modern appliances. Compared with UL 10269 (1000 Vac / 1250 Vdc), UL 1032 shares the same insulation wall table but carries a 90°C maximum temperature rating and adds optional covering, shield and jacket constructions within the style description.

Construction and Ratings

Insulation wall thickness scales with conductor size: 30 mils minimum average (27 mils minimum at any point) for 30–9 AWG, stepping up through 45, 60, 80, 95 and 110 mils to 125 mils minimum average for 1100–2000 kcmil. An optional 60°C or 80°C oil rating is available for circuits exposed to oil inside the appliance, and optional constructions include an extruded PVC covering, a shield, and an extruded PVC jacket (30 mils minimum average). Marking follows UL Subject 758 marking requirements, and RoHS/REACH documentation is available on request.

Permitted Use and Ordering

The permitted use for UL 1032 is internal wiring of appliances; tags may additionally indicate 3500 V peak — for electronic use only, which covers internal electronic circuits at elevated peak voltages. For applications outside internal appliance wiring, confirm application suitability before specifying. CableApex supplies UL 1032 from 100 m per color, in solid or stranded conductor and standard insulation colors, and answers B2B inquiries within 12 hours with pricing, lead time and packing details. Browse the UL 1032 products below by AWG size, or send your specification through any product page to request a quote.
